Generative UI with json-render

Ask a model for a section and you get one that is almost right. The usual fix is a stricter prompt, and it does not hold. Here is the fix that does, with the code, from a template you can clone.

The problem, in one paragraph

You ask for a pricing section. You get one. It is almost right. The heading is text-3xl where your scale says text-2xl. The card background is #f9fafb, nearly your surface token but not quite. There is a gradient nobody asked for.

One section, you fix by hand. Forty sections, and you no longer have a design system. You have a design system plus a thousand small betrayals of it.

So you write a stricter prompt. It does not work, and the reason is exact.

The fix: take the words away

Stop trying to constrain the output. Change the language instead.

You describe your own components once, with typed props. The model composes pages inside that list and nothing else. A wrong colour is not refused, it cannot be typed. This is what json-render does, and it is an open-source project from Vercel Labs.

How big is one piece?

This is the choice that decides everything else. How large is one thing the model is allowed to make?

Step 1: write the catalog

A catalog is a list of what may be said. Plain TypeScript, Zod schemas.

import { defineCatalog } from "@json-render/core";
import { schema } from "@json-render/react/schema";
import { z } from "zod";

export const catalog = defineCatalog(schema, {
  components: {
    Hero: {
      props: z.object({ headingLevel: z.enum(["1", "2"]) }),
      description: "Oversized headline, lede, two calls to action and a facts strip.",
    },
    ServicesLedger: {
      props: z.object({ heading: z.enum(["section", "page"]) }),
      description: "Six services as a ruled table of contents with a from-price.",
    },
  },
});

Three things there are doing the real work.

Every prop is a closed set. z.enum(["section", "page"]) means the model picks one of two things you designed. A third is an error caught before anything renders. Whenever you reach for a plain string, ask whether a list of choices would do. It usually would.

The description is the prompt. You never write a long system prompt. One sentence per component saying what job it does, and catalog.prompt() builds the rest. Write them for someone who cannot see the page: "six services as a ruled table of contents with a from-price" is useful; "hairline rows with a coral accent" is not, because the model is choosing by purpose.

There is no class, colour or size anywhere. That absence is the feature.

Step 2: point the names at real components

The registry maps each catalog name to the React you already shipped. At section level, one line each.

import { defineRegistry } from "@json-render/react";
import { Hero } from "../components/hero";
import { ServicesLedger } from "../components/services-ledger";

export const { registry } = defineRegistry(catalog, {
  components: {
    Hero: ({ props }) => <Hero headingLevel={props.headingLevel === "1" ? 1 : 2} />,
    ServicesLedger: ({ props }) => <ServicesLedger heading={props.heading} />,
  },
});

A registry component receives { props, children, slots }. This is the one file where class strings belong, because it is code you wrote and can lint.

Step 3: a page becomes a file

{
  "root": "page-1",
  "elements": {
    "page-1": { "type": "Page", "props": {},
      "children": ["services-ledger-1", "faq-1", "cta-1"] },
    "services-ledger-1": { "type": "ServicesLedger",
      "props": { "heading": "page" }, "children": [] },
    "faq-1": { "type": "Faq",
      "props": { "variant": "engagement" }, "children": [] }
  }
}

Flat, with children referenced by id. Odd at first, then you stop noticing, and you get two things for it: a model can stream it as patches, and any element can be addressed without walking a tree.

<StateProvider initialState={state}>
  <VisibilityProvider><ActionProvider>
    <Renderer spec={spec} registry={registry} />
  </ActionProvider></VisibilityProvider>
</StateProvider>

All three providers are required, even with no state, no visibility rules and no actions. The renderer's hooks throw when a provider is missing, and the error does not tell you which one. That is an hour you can skip.

A complete component, side by side

This is the whole of one real section from the worked example: a band of client names. First, what the model writes.

{
  "band": { "type": "ClientBandShell",
    "props": { "note": { "$state": "/clientBand/note" } },
    "children": ["list"] },
  "list": { "type": "ClientMarkList", "props": {}, "children": ["mark"],
    "repeat": { "statePath": "/clientBand/clients" } },
  "mark": { "type": "ClientMark",
    "props": { "name": { "$item": "" } }, "children": [] }
}

Three elements. $state reads a path from your data. repeat draws the children once per item. $item is the current item.

Now the React those names point at, unchanged from the shipped theme:

const clientMark = definePart({
  catalog: {
    props: z.object({ name: z.string().max(80) }),
    description: "One client wordmark in the client band's list.",
  },
  render: ({ props }) => (
    <li className="font-display type-d1 text-secondary-foreground">{props.name}</li>
  ),
});

const clientMarkList = definePart({
  catalog: {
    props: z.object({}),
    description: "The client band's four-column list of wordmarks.",
  },
  render: ({ children }) => (
    <ul className="grid grow grid-cols-2 gap-x-8 gap-y-5 sm:grid-cols-3 lg:grid-cols-4">
      {children}
    </ul>
  ),
});

And the data, exported from the section file so the component and the model read the same words:

export const CLIENT_BAND = {
  note: "Thirty-one companies since 2016, eight of them twice",
  clients,
};

That is the entire pattern. The JSON holds content and order. The React holds every class. Neither can reach into the other.

A repeating element draws its children once per item with nothing wrapped around them. So the repeating element is the <ul>, and its single child is the <li>. Getting that backwards is the most common first mistake.

Step 4: prove nothing changed

Here is the claim to be suspicious of: a page built from JSON renders the same as the one you wrote by hand. Not similar. The same. You can check it in about twenty lines.

const route = normalise(renderToString(createElement(HandWrittenRoute)));
const spec  = normalise(renderToString(createElement(SpecPage, { spec: SPECS.home })));
if (route !== spec) fail(firstDifference(route, spec));

Over all eight pages of the worked example, that prints:

ok home — 40627 bytes identical
ok work — 35690 bytes identical
ok services — 40293 bytes identical
ok team — 28759 bytes identical
ok contact — 35377 bytes identical
ok journal — 25188 bytes identical
ok legal — 19723 bytes identical
ok components — 173976 bytes identical
ok parity — 8/8 routes

Step 5: let the model write

Everything so far is deterministic. This part is small, because by now the interesting work is done.

import { streamText } from "ai";
import { catalog } from "@/render/catalog";

export async function POST(req: Request) {
  const { prompt } = await req.json();
  return streamText({
    model: "anthropic/claude-haiku-4.5",
    system: catalog.prompt({ customRules: ["Every route ends with the closing panel."] }),
    prompt,
  }).toTextStreamResponse();
}

Put whatever the visitor typed into state, never into your instructions. Then validate, and repair rather than throw: drop an unknown type, clamp a list that ran long, move the closing panel back to the end.

The worst a fully hijacked model can do here is produce a different valid arrangement of your own sections. It cannot emit a script, a link, a class or a colour, because none of those are in the vocabulary. That is the security argument for the whole approach.

Step 6: hand it back as React

A JSON page is a fine runtime and a poor deliverable. Walk the spec and emit the file you would have written:

export default function ServicesPage() {
  return (
    <div className="flex min-h-screen flex-col bg-background …">
      <SiteHeader />
      <main id="main" className="flex-1">
        <ServicesLedger heading="page" />
        <Capabilities />
        <Faq variant="engagement" />
        <Cta />
      </main>
      <SiteFooter />
    </div>
  );
}

In the worked example this round trip is byte-identical to the checked-in route on seven of eight pages, and a test holds it there. That test does more than it looks: if codegen can reproduce your routes exactly, your catalog lost nothing on the way in.

What it costs

About 100 kB, because the renderer is a client component and the sections come with it. Pages still prerender.

Whether to pay it is simple. If the page ships from source, run codegen and pay nothing. If a person edits it or a model assembles it live, pay it.

The visual cost was measured too: eight routes, four widths, both modes, sixty-four screenshot pairs against the hand-written original. Sixty were pixel-identical. The four that were not are one and eight pixels of text antialiasing.

Your first week

1. Catalog five sections. The five you use most. Props as enums only. One sentence each.
2. Registry and one spec. One line per section, then transcribe a real page into JSON by hand. This is the step that teaches you the format.
3. The parity test. Do not skip it. It is the whole warranty.
4. Make one section's content data. Pick a repeating one: a pricing table, a feature list.
5. Let a model compose. catalog.prompt(), a streaming route, validate and repair.
6. Codegen. Spec back to a route file, with a test that the round trip reproduces your existing routes.
7. Screenshots. Compare generated against hand-written at four widths in both modes. Settle lazy images first, or you will measure your screenshotter.

Three things to decide early

What stays out. Some components should never be generated. In the worked example the site header, the footer and a validated enquiry form are placed whole and never decomposed, because they are behaviour, not content. A form with five fields, pending states and a discard dialog is not a thing a model should assemble.

Who owns the words. Composition is cheap to generate and easy to check. Content is where the value and the risk both are. Use your best model for the words and a cheap one for the structure.

What your test compares. A gate that compares a generated page against your own copy of a component proves only that the two halves agree. If the component drifts, both move together and the test stays green. Compare against the source of truth. That exact hole cost a real defect in the worked example, caught by screenshots rather than by the test meant to catch it.
